Incada Duo

PDF download

Click the button to download this technical data sheet as a PDF.

Folding Box Board

Incada Duo is a laminated folding box board product based entirely on fresh fibres. The individual layers in the laminate has a multi-layered fibre composition and construction designed to maximise its stiffness whilst having a low density. The outer layers consist of bleached chemical sulphate pulp, and the middle layers of thermo-mechanically separated fibres (TMP). Pigment coating can be applied to one or both sides, and its unique composition is designed to ensure that the product family meets different end-use printability requirements.

Product description

Incada Duo combines excellent stiffness with high-quality print performance and visual appeal, making it well suited for displays and other applications where both aesthetics and structural strength are important. The standard version is made through back-to-back pasting of Incada baseboard, creating two identical printing surfaces. Its fully coated surfaces ensure consistent print quality, while the high whiteness provides good contrast and vibrant colour reproduction.

Application areas

This product is suitable for the following applications:

Holmen Iggesund end use box

Packaging

Holmen Iggesund end use graphics

Graphics

Incada Duo
Certifications & Standards

Product related

FSC® Mix

Food safety

Toy safety



FSC-C008588

SA-COC-012971

EC 1935/2004

EC 2023/2006

FDA 21 CFR

German BfR XXXVI

Normpack

EN 71 Part 3

EN 71 Part 9
All fibres from sustainable and controlled sources in compliance with the UK Timber Regulation 01/01/2021.
EcoVadis Platinum Medal awarded in 2026 (top 1% of all companies assessed).

Mill related

ISO 9001

ISO 14001

ISO 45001

ISO 50001

FSC®

For more detailed information about our certificates, visit holmen.com/boardandpaper/certifications.

Properties - both sides identical

Tolerances Methods/Remarks
Grammage (g/m²) 430-710 +/-6% ISO 536
Colour L* - PS 95.2 +/- 0.8 ISO 5631-2
Colour a* - PS 1.4 +/-0.6 ISO 5631-2
Colour b* - PS -7.2 +/-1.0 ISO 5631-2
Whiteness - PS 120 +/-2.5 ISO 11475
ISO Brightness R457 - PS (%) 91.5 - ISO 2470
Surface roughness PPS - PS (µm) 0.9 ≤1.3 ISO 8791-4
Board gloss 75° - PS (%) 50 +/-10 ISO 8254-1
Surface strength IGT blister - PS (m/s) 1.0 ≥0.85 ISO 3783
Surface strength IGT pick - PS (m/s) 1.0 ≥0.85 ISO 3783
Cobb - PS (g/m²) 30 - ISO 535

Common properties

Tolerances Methods/Remarks
Grammage (g/m²) 430-710 +/-6% ISO 536
Ply bond (J/m²) 140 ≥80 Tappi 569
Robinson taint <0.6 - EN 1230-2

Robinson taint value is below the detection limit of 0.6.

Grammage dependent properties

Tolerances Methods/Remarks
Grammage (g/m²) 430 460 480 520 570 610 660 710 +/-6% ISO 536
Thickness (µm) 665 735 785 885 965 1065 1170 1290 +/-6% ISO 534
Caliper (pt) 26.2 28.9 30.9 34.8 38.0 41.9 46.1 50.8 - -
Moisture content (%) 8.0 8.0 8.0 8.5 8.5 8.5 8.5 8.5 +/-1.5% ISO 287
Bending resistance L&W 15° - MD (mN) 1300 1650 1900 2250 2650 2920 3600 4200 - ISO 2493-1
Bending resistance L&W 15° - CD (mN) 650 850 950 1150 1350 1520 2000 2400 - ISO 2493-1
Bending moment Taber 15° - MD (mNm) 63 80 92 109 128 144 174 203 - -
Bending moment Taber 15° - CD (mNm) 31 41 46 56 65 73 97 116 - -

Bending Moment Taber is a calculated value based on a correlation factor of 20.7.
Please observe specification values are tentative and could be reviewed.

Test methods

All properties are measured in test climate 23°C/50% RH at Workington Mill. Tolerances and max/min levels, when stated, are based upon a 95% confidence interval within each production run. Read more about testing methods in our General Technical Information.

Latest version

Access the latest version of this spec sheet on:
holmen.com/boardandpaper/incada-duo
